LIGHTWEIGHT, FAST & EASY
The FootingPad® composite deck post footing system is engineered to provide the fastest, most economical means to raise your deck in record time. The FootingPad® system’s design is lightweight, evenly distributes deck post loads, and saves hours of back-breaking work. FootingPad can be used in most Type V construction subject to loading limits. Take a look at how FootingPad® compares to traditional concrete deck installation:
STRUCTURALLY SOUND AND CODE COMPLIANT
FootingPad® post footers are designed and engineered to replace concrete footings of equal diameter. They have been independently tested by NTA Testing Laboratories and certified code compliant (IBC & IRC) by the ICC-ES Evaluation Services. See ESR 2147.
Replaces Concrete Footings of Equal Diameter
10″ & 12″ FootingPads® will support a 4×4 or larger post. 16″ FootingPads® will support a 6×6 or larger post. Allowable loads are controlled by the type of supporting soil.
Total Allowable Load
10″ & 12″ FootingPads® will support a 4×4 or larger post. 16″ FootingPads® will support a 6×6 or larger post. Allowable loads are controlled by the type of supporting soil. 10″ FootingPads® have a total allowable load of 1,635 pounds based on 3000 psf soil capacity. 12″ FootingPads® have a total allowable load of 2,355 pounds based on 3,000 psf soil capacity. 16″ FootingPads® have a total allowable load of 4,167 pounds based on 3000 psf soil capacity.
